TorqueMaster 5 electric winch: maximum pulling force 40 kN, rated pulling force 32 kN and pulling speed 4-20 m/min. AC 380 V, 7.5 kW motor, dimensions 119 x 47 x 43 cm and 204 kg including control box.
The Electric Winch Machine TorqueMaster 5 is an industrial pulling and hoisting machine designed for controlled, heavy-duty operation. It delivers up to 40 kN of pulling force through a 7.5 kW copper-core motor, with a 4-20 m/min operating range, stepless speed adjustment, local and remote controls, and automatic power-off braking.
The 7.5 kW motor transfers power through a shock- and vibration-resistant shaft transmission and a high-strength reduction gearbox to the thickened drum. Operators can regulate the operating speed continuously from 4 to 20 m/min using the control panel or remote control. If the AC 380 V power supply is interrupted, the automatic braking system stops the winch.
| Model | TorqueMaster 5 |
| Power Supply | AC 380 V |
| Motor Power | 7.5 kW |
| Rated Pulling Force | 32 kN |
| Maximum Pulling Force | 40 kN |
| Pulling Speed | 4-20 m/min |
| Speed Adjustment | 4 gears + stepless adjustment |
| Control Methods | Control panel and remote control |
| Braking Method | Automatic power-off brake |
| Transmission | Shaft drive |
| Dimensions | 119 x 47 x 43 cm |
| Net Weight | 204 kg including control box |
| Powerful Copper-Core Motor | The 7.5 kW motor delivers up to 40 kN of pulling force for demanding work. |
| Stepless Speed Control | Allows smooth adjustment from 4 to 20 m/min for precise pulling or hoisting. |
| Dual Control System | Supports operation from the local control panel or from a distance with the remote control. |
| Power-Off Braking | Automatically stops the winch when the power supply is interrupted. |
| Separate Electrical Box | Makes the machine easier to move, operate, install, and maintain. |
| Efficient Shaft Transmission | Resists impact and vibration while reducing heating and slipping during operation. |
| High-Strength Gearbox | Supports smooth power transmission during heavy-load operation. |
| Thickened Drum | Resists pressure and wear during repeated pulling and hoisting work. |
| Typical Applications | Heavy-duty pulling, controlled hoisting, industrial operation, and remote-controlled work. |
The maximum pulling force is 40 kN.
Yes. The winch provides stepless speed adjustment from 4 to 20 m/min.
Yes. Operators can use either the local control panel or the remote control.
The automatic braking system stops the winch when the power is cut off.
The TorqueMaster 5 operates on an AC 380 V power supply.
The machine measures 119 x 47 x 43 cm and has a net weight of 204 kg including control box.
For equipment selection, share your required pulling force, operating speed, power supply, working route, and site conditions with our team. We can help you evaluate whether the TorqueMaster 5 matches the planned pulling or hoisting task.
